Magnaflux Model ZA-1633 Fluorescent Penetrant Testing Equipment System

ZA-1633 systems are stand-alone fluorescent penetrant inspection systems for light volume inspection of small to medium size parts, including aerospace fasteners, automotive parts and surgical implant inspection.

Three different system configurations are available:

• ZA-1633 for Method A for water washable penetrant testing has 6 stations

ZA-1633-Water-Wash-Penetrant-Inspection-System_PDS

     Method A – Water Washable
     Dimensions 56 x 28 x 36 in / 142 x 71 x 91 cm
     Stations (1) Penetrant
              (2) Drain
              (3) Rinse
              (4) Dryer
              (5) Developer
              (6) Inspection

• ZA-1633 for Method B post-emulsifiable, lipophilic has 8 stations

ZA-1633-Post-Emulsified-Lipophilic-Penetrant-Inspection-System_PDS

     Method B – Post Emulsifiable, Lipophilic
     Dimensions 70 x 28 x 36 in / 177.8 x 71.1 x 91.4 cm
     Stations (1) Penetrant
              (2) Drain #1
              (3) Emulsifier
              (4) Rinse
              (5) Drain #2
              (6) Dryer
              (7) Developer
              (8) Inspection

• ZA-1633 for Method D post-emulsifiable, hydrophilic has 9 station

  ZA-1633-Post-Emulsified-Hydrophilic-Penetrant-Inspection-System_PDS

  Dimensions 83 x 28 x 36 in / 210.8 x 71.1 x 91.4 cm
  Stations (1) Penetrant
           (2) Drain #1
           (3) Pre-Rinse
           (4) Drain #2
           (5) Remover
           (6) Final Rinse
           (7) Dryer
           (8) Developer
           (9) Inspection


Features

• 304 stainless steel tanks (16 gauge)
• Durable welded steel frame
• Digitally calibrated dryer control
• EV6000 UV lamp
• Stand alone inspection booth
• Visible light in inspection hood

Specifications

Electrical Requirements: 230V or 460V, 60Hz, ingle Phase

Tank Size: 15.8 x 33 x 14.8 in / 40.1 x 83.8 x 37.6 cm

Tank Capacity: 27 gal / 102 L

Dryer: Digitally calibrated temperature control

UV Lamp: EV6000 hand-held LED black light
