P-Series

Economical Power Pack Magnetic Current Generators

P-Series portable power packs are convenient and economical inspection units that are used in a wide range of magnetic particle inspection applications that require only moderate power.

These portable electromagntic current generators are ideal for inspecting large or heavy parts, in-service mobile equipment or job-site weld testing with magnetic particle inspection NDT method.

P-Series power packs are available in two configurations P-70 and P-1500 to meet a variety of mag particle inspection needs. Click on the tabs below for more details on these configurations.

Comparison

P-70

P-1500

Contact Current Capacity (amps)* AC 750 1,500
HWDC  750 1,500
Dimensions 17.5 x 9 x 7.5 in /
44.5 x 23 x 19 cm
22 x 9.5 x 9.5 in /
56 x 24 x 24 cm
Weight 35 lb / 16 kg 93 lb / 42 kg

* Rated with 2 sets of 15 ft / 4.6 m of 4/0 cable

Benefits

  • Find surface defects with AC current; switch cable connection to half wave DC (HWDC) for near-surface flaws
  • Locate defects in any direction using prods, central conductor, coil (wrap part with 3-5 turns of cable)
  • Infinitely variable current control
  • Demagnetize parts in AC mode by slowly turning the current dial to zero
  • Built-in automatic-reset circuit breaker
  • May be used as the main power source for the Mag Kit modular bench inspection system
  • Comes standard with 15 ft / 4.5 m remote control cable

Part Numbers

Product Name Specifications Part Number
P-70
  • Length: 17.5″ (44.5 cm)
  • Width: 9″ (22.9 cm)
  • Height: 8″ (20.3 cm)
  • Maximum Output*: 750 amps, AC or HWDC
  • Available Voltages: 115,230, 50 or 60 Hertz; single phase power
  • Line Current: 26 amps @ 115 VAC; 13 amps @ 230 VAC
  • Maximum Duty Cycle: 2 minutes ON, 2 minutes OFF
  • Unit Weight: 35 lbs (15.9 kg)

Note: Current ratings are based on the use of two 15-foot length 4/0 cable, 4/0 cable not included, must be purchased separately.

115V: 628822


230V: 628826

P-1500
  • Length: 22″ (55.9 cm)
  • Width: 9.5″ (24.1 cm)
  • Height: 9.5″ (24.1 cm)
  • Maximum Output: 1500 amps, AC or HWDC
  • Available Voltages: 230,460, 50 or 60 Hertz; single phase power
  • Line Current: 42 amps @ 230 VAC; 21 amps @ 460 VAC
  • Maximum Duty Cycle: 2 minutes ON, 2 minutes OFF
  • Unit Weight: 93 lbs (42.2 kg)

Note: Current ratings are based on the use of two 15-foot length 4/0 cable, 4/0 cable not included, must be purchased separately.

230V: 628824


460V: 628825

Retro-Fit Kit
  • Converts Either-End connectors on P-Units to Lug terminals
  • Includes three (3) Lug terminals and all required hardware
  • Includes installation guide
For either P-70 or P-1500: 628882


Recommended Accessories:

626350-180: 15 ft/ 4.6 m Lugs at both ends

628832: Lug to Quick Connect Adapter Kit

628833-180: 15 ft / 4.6 m 4/0 cable assembly with 628828 QC-F and 628829 QC-M quick connectors on each end
