A professional grade eddy current instrument designed for both standard and complex inspection applications.
The EddyView Pro is a dual-frequency
instrument designed with split screen capability for high speed bolt hole scanning. It provides conductivity and non-metallic thickness measurement, and the ability to interface with peripheral devices and automated systems.
Designed to be used by the professional, the EddyView Pro includes all the features of the EddyView Prime, and additional features that allow for both standard eddy current inspection and complex inspections. The EddyView Pro features include capability for automated production testing. Ethernet, RS-232, alarm outputs and high rates of data acquisition adds to the flexibility of the instruments system integration capability. The EddyView Pro is the perfect fit for use in the field, the laboratory, or in production

The USM Go+ ultrasonic flaw detector offers you the performance and features of a tabletop ultrasonic detector in a small, ultra-portable handheld instrument weighing less than 2 pounds (907 grams) for maximum portability in the field. Its ergonomic design, useful features and big performance are the result of carefully listening to the experience of the people in the field who, through their everyday practice, know best what it takes to do a good job.

Range of applications

The USM Go+ has been designed to provide flaw detection capability in inspection situations throughout the industrial and process spectrum, from aerospace to power generation and from the automotive sector to the oil and gas industry.

Weld Inspection:
• Trigonometric projections with curvature correction.
• AWS D1.1 sizing
• DAC/TCG
• DGS
• Color Leg

Inspection of Forgings and Castings:
• Manual PRF adjustment
• Phantom echo indicator
• DGS
• Backwall Echo Attenuator (BEA)

Inspection of rails:
• High PRF (up to 2000 Hz)
• Lightweight: 850 g (1.87 lb.)
• Small size and ergonomics

Inspection of Composites:
• RF Display
• 2 gates with B-start triggered with echo in gate A
• TCG correction with high slope 120 dB/μs
• Reflector depth indicated in layer

For more demanding applications:
• Narrow band filters
• Low noise digital amplifier
• Square wave pulser

Verlux 550 has same intensity but uses green LEDs. This makes the radiographs easier to view.

About Green Light:

Verlux 550 uses LEDs with a narrow wavelength of 550nm which is the maximum sensitivity of the human eye; so when comparing equal intensity of green and white light, the green appears brighter. this makes the radiographs easier to view.

Light Intensity:

MAX. Luminance: >100,000 Cd/m2

Density: >4.0 Density

Uniformity: 0.95

AND no warm up time

FEATURES:
Aluminum / Plastic Case

Adjustable Support Handle

Foot Switch & Dimmer Control

POWER: 85-264VAC 47~63Hz (full range)

Power Consumption 120W

OTHER ADVANTAGES:

LOW HEAT: – will not damage films

LOW POWER – energy saving

COMPACT – small & lightweight

SAFE – sealed and insulated

MODERN DESIGN – stylish & simple

OVERALL DIMENSIONS:

Length 390mm (15.3″)

Width 180mm (7.1″)

Height 50mm (1.9″)

Weight 3kg (6.6Ib)

VIEWING AREA:

Length 200mm (8″)

Width 80mm (3 1/8″)

The illuminators meet the requirements of EN25580: 1992; ASTM E 1390-90 and ISO 5580: 1995. They are CE Marked.
