Hi-Temp D-350 is used with Hi-Temp KO-17 Penetrant and Hi-Temp KO-19 Remover. Consists of refined white particles suspended in non-chlorinated, volatile solvent (alcohol). Available only in spray cans. Performs on elevated temperature surfaces; 200°F to 350°F. At lower temperatures D-350 dries more slowly and adheres quickly, requiring greater effort to remove upon completion of inspection process. To remove, wipe with water dampened toweling. Approved Group I and III under MIL-1-25135-C.

Penetrant System Category:
Developer Non-Aqueous Form D & E
Specifications:
QPL SAE AMS 2644 Form D & E
ASTM E165

Comes in a case of 9 – 16oz Aerosol Cans

DP-50 is a red colored, water-washable dye penetrant liquid used to locate cracks, laps, pores, lack of bonding, and similar surface flaws in any insoluble, nonporous substance including both ferrous and nonferrous metals, ceramics, glass and many plastics. Referred to as the “visible dye penetrant” method or “color contrast” method of inspection for weld inspection.

Complies with low sulfur and low halogen requirements.

Specifications: SAE AMS 2644 & QPL, MIL-I-25135 Revisions C, D, & E, ASME Code NDT, Sec V

Classification: Type 2, Methods A and C

DR-60 Cleaner-Remover is used in the penetrant process to remove excess, nonwater-washable penetrants from part surfaces. DR 60 Cleaner / Remover is used with Sherwin DP-40 Dye Penetrant (visible red) and Sherwin RC-65 and RC-77 Fluorescent Penetrants. It is a manual “wipe on” and “wipe off” material and, consequently, recommended for small areas. DR-60 may also be used for generally cleaning oily, dirty surfaces. DR-60 is especially suitable for cleaning prior to the application of inspection penetrants.

Complies with low sulfur and low halogen requirements.

Specifications: SAE AMS 2644 & QPL, MIL-I-25135 Revisions C, D & E, ASME Code NDT, Sec V

Classification: Solvent Removers (Method C)
Approved for use with: All fluorescent and visible penetrants

Comes in a case of 9 – 16oz Aerosol Cans

Glo-Netic spray is used in the magnetic particle crack detection process by critical industries, including nuclear power, aersopace, shipbuilding and construction. The particles respond to magnetic leakage fields created by cracks and other flaws. They rapidly collect at such fields and when viewed under black light, they reveal and profile flaws as bright, glowing yellow-green marks.

Comes in a case of 9 – 16oz Aerosol Cans

Visible dye penetrant, approved under MIL-1-25135 and AMS-2644. Finds flaws on surfaces at temperatures up to 350°F. Saves time for weld inspection before complete cooling (maintains pre-heat temperature), in-service inspection of chemical processing equipment, etc.

KO-17 along with KO-19 Cleaner/Remover and D-350 Developer comprise Sherwin Incorporated’s HI-Temp Penetrant System, which works at temperatures above which ordinary penetrants are ineffective.

Penetrant System Category:
Visible Type 2 Water-Washable
(Methods A & C)
Specifications:
QPL SAE AMS 2644 A & C
ASTM E165

Comes in a case of 9 – 16oz Aerosol Cans
